Helium liquefaction and medium and high energy consumption helium refrigeration.

Author: Guy GISTAU BAGUER

Publication date: July 10, 2012

You do not have access to this resource.
Click here to request your free trial access!

Already subscribed? Log in!

Overview

Français

ABSTRACT

This article presents two related activities: helium liquefaction and helium refrigeration (also called liquefaction/refrigeration). It aims to provide an understanding of the operation of the machinery, and presents certain design and construction methodologies. It uses examples to outline basic liquefaction/refrigeration cycles, and simple calculations relating to the key parameters of these cycles. Specific cycles, used to obtain high levels of power or temperatures below -268.65°C are then described and discussed. Several concise technological reminders on key components are given, focusing on the specific aspects of the use of these components for refrigeration/liquefaction purposes. Finally, the control process is described and linked to the continued effectiveness aspect according to the operating conditions.

Read this article from a comprehensive knowledge base, updated and supplemented with articles reviewed by scientific committees.

Read the article

AUTHOR

  • Guy GISTAU BAGUER: Engineer École Nationale Supérieure des Arts et Métiers ENSAM - Former head of helium liquefaction/refrigeration at Air Liquide - Cryogenics Consultant

 INTRODUCTION

This dossier is part of a series of articles on cryogenics.

All cryogenic activity starts with obtaining low temperatures.

Temperatures above 80 K (– 193 °C), the approximate boiling point of liquid nitrogen, are obtained industrially during the liquefaction of natural gas (methane) [J 3 601] and the separation of gases from air [J 3 600] .

Liquid hydrogen, which boils at around 20 K (– 253°C), is also liquefied industrially in much smaller quantities [J 3 603] .

Helium, on the other hand, has a boiling point of around 4 K (– 269°C), and is a rarer, more expensive gas, reserved for uses such as superconductivity, which require very low temperatures. Helium liquefaction/refrigeration is currently an industrial activity, but its diffusion is still relatively limited, as it is linked to the development of superconductivity. The two main fields concerned are :

  • helium cooling and maintenance of the huge cryogenic structures of large gas pedals and particle storage rings for physics research;

  • helium liquefaction at production sites (helium is extracted from natural gas [J 3 605] for transportation and commercial distribution in liquid form, in order to reduce costs).
