3. Ground-to-ground transmission network architecture
3.1 Architecture
The chosen architecture is based on the deployment of three ATM loops carrying information.
Voice / Data / Images between the PCC and the various nodes (stations) they serve.
This general architecture is shown in figure 13 .
